ISO lumens

8,400

ANSI lumens

7,500

Contrast ratio

Full On/Off (Christie Real Black enabled): 300,000:1 , Full On/Off (Christie Real Black disabled): 1,200:1

Dynamic contrast

6,000:1

Display type

1DLP 0.67" DMD

Resolution

WUXGA (1920 x 1200)

Illumination type

Laser phosphor with Christie BoldColor Technology

Illumination performance (hrs)

20,000 to 50% brightness

Scan rates

Horizontal: 15-91kHz Vertical: 24-85Hz

Pixel clock rate

162 MHz (1600 x 1200); 154 MHz (1920 x 1200)

Signal inputs

• Standard:
• - HDMI x 2
• - 3GSDI (BNC)
• - DVI-D (digital only)
• - VGA (HD15)
• - HDBaseT (RJ45 x1)
• - RJ45 x1 (Control over wired network connection)
• 3D:
• - HDMI 1.4, HDBaseT - Frame Packed, Top/Bottom, Side By Side/frae sequential (up to 1080p @ 120 Hz)
• - Up to 1080p @ 120Hz output
• - 3D Sync out (BNC) – for genlocking projectors or controlling emitter or polarizer
• Signals:
• - HDTV formats VGA through to WUXGA (1920 x 1080)
• - Horizontal and vertical scaling while maintaining aspect ratio (all inputs)

Signal outputs

• - 3GSDI x 1 (BNC)
• - HD15 x 1

Monitor out

• 3GSDI x 1 (BNC)

Control and networking

• - RS-232 in
• - Control via HDBaseT
• - Ethernet (10/100) RJ-45 with ChristieNET™ connectivity
• - Built-in backlit keypad
• - Wired remote control (3.5mm stereo)
• - loop out available for daisy chaining

Lens mount

• - Tool-free lens insertion system
• - Boresight adjustable
• - Motorized horizontal and vertical lens offset
• - Motorized zoom and focus adjustment

Lens options

• - Lens 0.75-0.95 Zoom G/GS
• - Lens 0.95-1.22 Zoom G/GS
• - Lens Zoom HP G/GS 1.22-1.52
• - Lens 1.52-2.89 Zoom G/GS
• - Lens 2.9-5.50:1 Zoom G/GS
• - Lens UST 0.36 (140-133108- XX)

Offsets

• +/- 100% vertical (+/- 600 px)
• +/- 30% horizontal (+/- 288 px)

Dissipation

• - Normal Mode: 3071 BTU/hr
• - ECO1 Mode 2525 BTU/hr
• - ECO2 Mode: 1689 BTU/hr

Audible noise

• - 36dB(A) standard mode
• 32dB(A) eco mode

Dimensions (L x W x H)

• 19.9 x 17.95 x 7.6" (505 x 456 x 190mm) w/o feet or lens

Weight

• 52.4lb (23.7kg) w/o lens

Shipping dimensions (L x W x H)

• 24.65 x 23.43 x 13.74" (626 x 596 x 349mm)

Shipping: 66.3lb (30kg)

• - Temperature: 32-104°F (0-40°C)
• - Humidity: 10-85% noncondensing

Regulatory

• - Contact Christie for timing of certifications: UL/CSA/IEC 60950-1
• - FCC Class A, CE, FDA, CCC, KC, PSE, EAC, BIS, VCCI, RCM, TER
• - This product conforms to all relevant European directives, standards, safety, health and environmental concerns
• - RoHS, REACH, WEEE

Limited warranty

• - 3 years parts and labor on the projector
• - 3 years or 20,000 hours parts and labor on the illumination system*
• - Contact an authorized Christie representative for full details of our limited warranty
• - *Please reference the Christie Standard Limited Warranty document for details.

Standard accessories

• - IR remote with wired remote jack (wire not included)
• - AC line cord for projector head
• - Rear input/keypad panel cover
• - User manual
